Motherboard Support
|
ATX, Micro-ATX, Mini-ITX
|
Enclosure Type
|
Mid-Tower
|
Case Material
|
SGCC Steel, Ultra-Clear Tempered Glass
|
Dimensions
|
Height (with feet): 435 mm / 17.13 in
|
|
Width: 287 mm / 11.3 in
|
|
Depth: 415 mm / 16.34 in
|
|
Weight: 9.4 kg
|
Compatibility & Clearance
|
CPU Cooler Height: 163 mm / 6.42 in
|
|
GPU Length: 365 mm / 14.37 in
|
|
PSU Length: 200 mm / 7.87 in
|
|
Cable Management: 91 mm / 3.58 in
|
|
Top Radiator: 30 mm / 1.18 in
|
Front I/O Ports
|
USB 3.2 Gen 1 Type-A: 2
|
|
USB 3.2 Gen 2 Type-C: 1
|
|
Headset Audio Jack: 1
|
Expansion Slots
|
Standard: 7
|
|
Vertical: 0
|
Drive Bays
|
2.5": 2
|
|
3.5": 1
|
Fan Support
|
Front-Right: 3 x 120 mm (3 x F120 RGB Core case version included)
|
|
Top: 3 x 120 mm / 2 x 140 mm
|
|
Bottom: 2 x 140 mm
|
|
Rear: 1 x 120 mm
|
|
Filters: High-Performance Mesh
|
Radiator Support
|
Top: Up to 360 mm
|
|
Rear: Up to 120 mm
|
Fan Specs
|
Model: F120 RGB Core Fan (Case Version)
|
|
Speed: 1300 ± 130 RPM
|
|
Airflow: 55.17 CFM
|
|
Static: 1.27 mm - H₂O
|
|
Noise: 26.1 dBA
|
|
Fan Connector: 3-pin
|
